Here you can find DIY articles on how to improve your K40 machine.
We focus on alot of different guides, everything from improving your smoke assist to better alignments.

Warning for new machine owners – grounding issues

This is a short warning with information how to solve the issue. More and more machines are delivered with deadly configuration on the grounding of the electronics. In China, the electric standard is not well built and many houses still do not have ground solutions in their house. So the machines are built by their standard, when we in EU or US or other parts of the world often have a good ground setup already in our homes since many years. If [...]

Read more...

Mirror alignment – the ultimate guide

Welcome to the ultimate alignment guide for your laser machine. This guide has some tips and hints regarding the popular K40 machine type, but this can be used for any laser machine on the market as the science behind movement of a laser beam is the same on all of them. 90% of the errors in laser machines are not skewed or non-square gantrys, it´s bad alignment of the three mirrors in the machine not lining up with each other. Some of [...]

Read more...

Setting the proper focus in your K40

Focus is very important for your work, if you are out of focus you will lose power or get strange effects when engraving. This is the most common issue with new users on the k40 machine, the information from the seller how to use the k40 is very limited so this information is not there and a new user tend to search for other problems causing it, when it´s actually the bed and focal distance doing it. So, what is focus? You [...]

Read more...

K40D the upgrade project – part one

The K40D is well known for beeing one of the better K40 versions out there, with it´s upgraded controller board (HT Master) and the famous gold-ish styled gantry. Is it really possible to upgrade this beast? sure, or, maybe? let´s find out! This project will be massive with deep diving into most of the stuff the laser is made up of, everything from the controller, water cooling, electric and buttons and so on. Even if you have a regular K40 you can [...]

Read more...

Upgrade your power supply – save money and time

This article is just the findings and results we found on several PSU´s but we cannot yet explain why or how this happens. Are you a electric engineer or have knowledge about the workings of the PSU and able to explain this phenomena in greater detail? comment below or contact me trough email – thanks! The power supplys in our beloved K40 machines are poorly built, the power in them is barely enough for running the machine itself. I have been following [...]

Read more...

Troubleshooting a “no fire” issue

Quick troubleshooting when the machine is not firing the laser any more. To begin with, make sure all wires and connections are good in the machine and make sure all cables are where they should be. Read up on the grounding-article here 1: Start the machine Does the machine home to top left position? if it does – go to #2 If it does not move – check fuses in the back of the machine, and inside the PSU – do this without power [...]

Read more...

Install a mA-meter on your K40 laser

Adding a mA-meter to your machine is one of the most important modifications you can do on this machine. The mA-meter will read the power trough your laser tube allowing you to set the power to a safe value to prevent the laser tube from over powering and thus saving the life span of the laser tube. Read more here about the most common reasons why your laser tube dies. Tools needed – Wire stripper, cutter and crimp tool. – Pliers or small wrench [...]

Read more...

Upgrade your analog power knob

This is a upgrade of the analog power potentiometer to give you better control over the power level. It´s also easier to remember a number than a location of the pot. You can buy this from me prebuilt, ready to connect to your machine here. Or follow this guide to make your own! If you want to convert your digital K40 to analog with this solution – check out this conversion article. Tools you need – Soldering iron and solder – Wire stripper and cutter Parts [...]

Read more...

Upgrades & improvements on the K40

The K40 machine is a awesome little product who makes it easy for hobby and semi-pro use to get going with laser cutting or engraving. It´s far from perfect and needs a hand to work as you intended. First reading should be the article about checking your machine – read it here. Water cooling Coolant tank Depending on where you live, it might be a good option to have a bigger tank 15-25L or more. If you live in a hot climate, you need a [...]

Read more...

Mirror alignment – no more sweat and tears – Updated!

This is the old alignment guide – check out the new guide here! Mirror alignment is the action many of us fear the most, looking at videos and reading guides and after two weeks your mirrors are still not aligned. Many of the guides and how to´s forget the most important part of aligning, that the pieces you try to align actually are aligned themselves. I have therefore made this guide in three parts, with three steps in each part., how you [...]

Read more...
