Lens & mirrors

Lens & mirrors

Mirrors and lens in your machine is actually very important.
The beam created in the laser tube travels between (at least) three mirrors and one lens before hitting your material.

The first upgrade everyone should do to their K40 is to upgrade the mirrors and lenses, as the provided ones with the machine are budget stuff noone should use, throw it away.
I don´t say this because we want to sell mirrors, order from Ebay if you want, but atleast change your mirrors, you will be happily surprised when you installed the new mirrors and lens.

Mirror alignment – the ultimate guide

Welcome to the ultimate alignment guide for your laser machine. This guide has some tips and hints regarding the popular K40 machine type, but this can be used for any laser machine on the market as the science behind movement of a laser beam is the same on all of them. 90% of the errors in laser machines are not skewed or non-square gantrys, it´s bad alignment of the three mirrors in the machine not lining up with each other. Some of [...]

Read more...

Setting the proper focus in your K40

Focus is very important for your work, if you are out of focus you will lose power or get strange effects when engraving. This is the most common issue with new users on the k40 machine, the information from the seller how to use the k40 is very limited so this information is not there and a new user tend to search for other problems causing it, when it´s actually the bed and focal distance doing it. So, what is focus? You [...]

Read more...

Mirror alignment – no more sweat and tears – Updated!

This is the old alignment guide – check out the new guide here! Mirror alignment is the action many of us fear the most, looking at videos and reading guides and after two weeks your mirrors are still not aligned. Many of the guides and how to´s forget the most important part of aligning, that the pieces you try to align actually are aligned themselves. I have therefore made this guide in three parts, with three steps in each part., how you [...]

Read more...

Cleaning your mirrors and lens

Mirrors ans lenses are delicate products and should be handled with care. Here is my suggestion of how to clean your mirrors and lenses with least damage and risk of scratching the surface. Suggested tools – Gloves (wool/cotton or ESD type) – Tweezers – Denatured alcohol or Isopropyl alcohol – Micro fiber cloth Caution Si-mirrors and ZnSe lens has a coating you dont want on your fingers, aswell as your fingers contain oils you don´t want on your lens/mirror. Always use gloves when handling mirrors and lenses. There [...]

Read more...

Mirror types for your Laser

There is a lot of different types of mirrors for our lasers. Some better than others, and some you will not see any difference on the K40. Contact us if you need help choosing mirror for your machine. Si Mirror Silicon Glass Gold Coated. Good reflective index for our machines (less than 50w) High reflective index, needs cleaning more often. Cu Mirror Copper mirror, better than MO, a bit below SI when talking about reflective index Mo Mirror Molybdenum mirror. Can withstand alot of “abuse” but have less [...]

Read more...
